MODEL SPECS |
Maximum Power | 8.3 kW {11 PS} / 8,000 rpm |
Maximum Torque | 12.0 Nm {1.2 kgfm} / 6,000 rpm |
Engine | 4-stroke Single |
Displacement | 144 cc |
Bore x Stroke | 58.0 x 54.4 mm |
Compression Ratio | 9.5:1 |
Valve System | SOHC, 2 valves |
Fuel System | Carburettor: Keihin PB20 |
Ignition | Digital DC-CDI |
Starting | Electric |
Cooling | Air-cooled |
Lubrication | Forced lubrication, wet sump |
Transmission | 5-speed, return |
Primary Reduction Ratio | 2.880 (72/25) |
Gear Ratio: 1st | 2.667 (40/15) |
Gear Ratio: 2nd | 1.895 (36/19) |
Gear Ratio: 3rd | 1.474 (28/19) |
Gear Ratio: 4th | 1.182 (26/22) |
Gear Ratio: 5th | 1.000 (24/24) |
Final Reduction Ratio | 3.923 (51/13) |
Clutch | Wet multi-disc, manual |
Final Drive | Chain |
Frame | Perimeter, box-section, high-tensile steel |
Front Suspension | ø33 mm telescopic fork |
Rear Suspension | Uni Trak, single shock with piggyback reservoir, adjustable compression and rebound damping, and adjustable spring preload |
Front Wheel Travel | 180 mm |
Rear Wheel Travel | 180 mm |
Rake | 27.0° |
Trail | 96 mm |
Steering Angle (L/R) | 41° / 41° |
Front Tyre | 70/100-19 42M |
Rear Tyre | 90/100-16 52M |
Front Brake/s | ø220 mm petal disc |
Front Caliper/s | Dual-piston |
Rear Brake | ø186 mm petal disc |
Rear Caliper | Single-piston |
Dimensions (LxWxH) | 1,895 x 790 x 1,075 mm |
Wheelbase | 1,285 mm |
Road Clearance | 255 mm |
Seat Height | 800 mm |
Curb Weight* | 95 kg |
Fuel Capacity | 5.8 litres |
Model Code | KLX140BSFNN |
*Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
**Estimated dry weight does not include all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).
KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. 2021 Kawasaki Motors Pty Ltd.
Specifications subject to change.
